7.6m Fire Tender Mounted Pneumatic Telescopic Mast Tower Light
Item #: NR-HD7600-4000
4x1000W Halogen Lamps
7.6m Pneumatic Telescopic Mast
AC220V/50Hz Power Supply
| Product Name |
7.6m Fire Tender Mounted Pneumatic Telescopic Mast Tower Lights |
| Item No. |
NR-HD7600-4000 |
| Lamps |
4x1000W Halogen Lamps (default), or 4x200W LED Flood Lights |
| Pneumatic Telescopic Mast |
1> Extended Height: 7.6m
2> Retracted Height: 2.05m
3> Payloads: 70kg Maximum
4> Working air pressure: 0.2Mpa/29PSI
5> Number of sections: 6 sections
6> Section diameter range: 55mm~160mm
7> Materials: Aluminum alloy 6063T5
8> Mast weight: 60kg approx. |
| Turn Tilt Mechanism |
420 degrees turning and tilting |
| Controller |
Remote control by wireless controller
Electric control box control
Wire cables controller
control mast extend/retract, lights lighting on/off.
turn tilt mechanism tuning and tilting.
automatic restore to original position. |
| Power Supply |
AC220~240V/ 50Hz Power supply |
| Key Features |
Automatic restore to original position.
Electric Air Compressor built inside of control box.
Remote control
Mast automatic extend/retract |
Vertical Mast Light
•Tilt and turn unit: 360 degrees rotation in turning and tilting, IP67
•Pneumatic telescopic mast with inside electric cables
•4x1000W halogen, 4x1000W metal halide, 4x150W LED, 4x300W LED floodlights
•Wireless and wired remote control
•Compact electric control box/ electric air compressor build inside or outside
•One button restore function
•Aluminum alloy materials for masts, tubes thickness 5mm
•Dual Action Tilt and Turn available
| ITEM # |
MAST HEIGHT |
LIGHTS |
Sections |
Base Section Dia. |
Power Supply |
Note |
| NR-HD4500-4000 |
4.5m |
4x1000W Halogen |
4 |
110mm |
AC220/50Hz |
Inside cables, inside compressor |
| NR-HD6000-4000 |
6.0m |
4x1000W Halogen |
4 |
110mm |
AC220/50Hz |
Inside cables, inside compressor |
| NR-HD6000-600L |
6.0m |
4x150W LED |
4 |
133mm |
AC220/50Hz |
Inside cables, inside compressor |
| NR-HD6000-4000M |
6.0m |
4x1000W Metal halide |
4 |
133mm |
AC220/50Hz |
Inside cables, inside compressor |
| NR-HD7500-4000 |
7.5m |
4x1000W Halogen |
5 |
133mm |
AC220/50Hz |
Inside cables, inside compressor |
| NR-HD7500-4000M |
7.5m |
4x1000W Metal Halide |
5 |
133mm |
AC220/50Hz |
Inside cables, inside compressor |
| NR-HD7500-1200L |
7.5m |
4x300W Metal Halide |
5 |
133mm |
AC220/50Hz |
Inside cables, outside compressor |
| NR-HD9000-4000 |
9m |
4x1000W Halogen |
6 |
160mm |
AC220/50Hz |
Inside cables, outside compressor |
| NR-HD9000-4000M |
9m |
4x1000W Metal halide |
6 |
160mm |
AC220/50Hz |
Inside cables, outside compressor |
| NR-HD9000-1200L |
9m |
4x300W LED |
6 |
160mm |
AC220/50Hz |
Inside cables, outside compressor |
