    Product Details:

    Place of Origin: China
    Brand Name: nrentech
    Certification: ISO/CE
    Model Number: NR-1500-3200-50D

    Payment & Shipping Terms:

    Minimum Order Quantity: 1
    Price: USD 500~800/unit
    Packaging Details: carton box.
    Delivery Time: 20 days
    Payment Terms: T/T
    Supply Ability: 200 units per month
    Contact Now
    Detailed Product Description
    Materials: Aluminum Alloy AL6063T5 Extend Height: 3.5m
    Retract Height: 1.5m Number Of Sections: 3
    Section Dia.: 56~87mm Working Air Pressure: 0.2Mpa/29PSI
    Weight: 10kg Approx. Inner Cables: Electric Cables Mounted Inside For Lighting
    Accessories: 1xtop Flange, 1x Bottom Flange, 1x Air Hose Pipe Optional Accessories: Electric Air Compressor, Side Mounting Brackets

    3.5m pneumatic telescopic mast inside electric wires-4x2.5 mm^2
    1.5m retraction height
    50kg payloads maximum
    3 sections
    non-locking collar (suitable for remote control extension/retraction)
    section dia. 56mm~87mm
    mast weight 10kg approx.
    inside electric wires 4x2.5mm^2
    application for portable mobile light tower
    compact electric control box supplied


    Tower Light Mast

    Part # Payload Extended Height Retracted Height Mast Weight Sections Sections Diameter Collar Type Operate Pressure Internal Cables
    NR1300-2700-25D 25kg/55lb 2.7m/8.9’ 1.3m/4.3’ 11kg/24lb 3 43~70mm/1.7~2.8” Non-locking 0.2Mpa/29PSI RVV 4x1.5mm2
    NR1270-3200-35D 35kg/77lb 3.2m/10.5’ 1.27m/4.17 14kg/30.8' 4 43~87mm/1.69~3.43" Non-locking 0.2Mpa/29PSI RVV 4x 1.5mm2
    NR1520-4200-35D 35kg/77lb 4.2m/13.8’ 1.52m/5’ 16kg/35.2lb 4 43~87mm/1.69~3.43" Non-locking 0.2Mpa/29PSI RVV 4x 1.5mm2
    NR1500-4500-50D 50kg/110lb 4.5m/14.8’ 1.52m/4.9’ 25kg/55lb 5 51~118mm/2.1~4.65" Non-locking 0.2Mpa/29PSI RVV 4x 2.0mm2
    NR1750-6000-50D 50kg/110lb 6m/19.7’ 1.75m/5.74’ 35kg/77lb 5 51~118mm/2.1~4.65" Non-locking 0.2Mpa/29PSI RVV 2x2.0mm2
    NR1750-6000-70D 70kg/154lb 6m/19.7’ 1.75m/5.74’ 45kg/99lb 5 66~140mm/2.6~5.51" Non-locking 0.2Mpa/29PSI RVV 2x2.5mm2 + 4x1.5mm2
    NR1950-6500-100D 100kg/220lb 6.5m/21.3’ 1.95m/6.4’ 65kg/143lb 5 82~160mm/3.22~6.3" Non-locking 0.2Mpa/29PSI RVV 2x1.5mm2 + 8x2.5mm2
    NR1950-6500-300D 300kg/660lb 6.5m/21.3’ 1.95m/6.4’ 80kg/176lb 5 140~229mm/5.5~9" Non-locking 0.2Mpa/29PSI RVV 12x2.5mm2
    NR2000-8000-100D 100kg/220lb 8.0m/26.2’ 2m/6.6’ 80kg/176lb 6 82~180mm/3.22~7.1" Non-locking 0.2Mpa/29PSI 7x AWG14
    NR2200-9000-50D 50kg/110lb 9m/29.5’ 2.2m/7.22’ 65kg/143lb 6 51~140mm/2.1~5.51" Non-locking 0.2Mpa/29PSI RVV 4x1.5mm2
    NR2500-9000-300D 300kg/660lb 9m/29.5’ 2.5m/8.2’ 150kg/330lb 5 140~229mm/5.5~9" Non-locking 0.2Mpa/29PSI RVV 12x2.5mm2
